SCM Pratix S 15 A

Ref : 2689742-15-MT

Condition : Used

Manufacturer : SCM

Model : Pratix S 15 A

Nb Of Axis : -

Year(s) : 2012

Quantity : 1

Location : Seller or machines location:
AMERICA North (USA-Canada-Mexico)

Worktable dimensions: 145″ x 61″
Z -Axis stroke: 9.84″
Spindle speed: 24,000 RPM
Electrospindle (S1/S6 rating): 7.5 HP / 9HP
Tool Changer: 10 position
Spindle Taper: HSK 63
Boring Block (7) Spindles: 6,000 RPM
Maximum positioning vectorial speeds:
X/Y axis: 115 feet/minute
Electrics: 208/230/460 volts, 3-phase, 60 cycles

EQUIPPED WITH:
Windows Based Operating system
17” Flat Panel Monitor
Remote Pendant with 7″ Display
7-Spindle Boring Block
Touch Probe
Spindle Air Blowers
Built In Vacuum Pumps- 2 Zones
