Kaiser KSTU 1250-12.5-3PR 125 ton

KAISER KSTU 1250-12.5-3PR
Construction year 1997

Press capacity 125 ton
Ram stroke adjustable 30 - 220 mm
Slide adjustment 100 mm
Shut height (stroke down, adjustment up) 450 mm
Free frontal opening L-R 1.290 mm
Free lateral opening F-B 450 mm
Table surface area 1.250 x 800 mm
Slide area 1.250 x 650 mm
Hole in table 1.050 x 260 mm
Number of strokes 30 - 220 s.p.m.
Table height over floor 1.200 mm
Required power 39 kW
Height over floor approx. 3.800 mm
Dimensions L x W x H 3.500 x 2.200 x 3.800 mm
Weight of machine approx. 21,5 ton
