Biesse, Weinig
EUROPE (Western and Northern)
Machinery for window and door production Weinig, Biesse
Currently, this system is used to manufacture wooden windows, wood-aluminum windows,
block frame elements, casement windows, front doors, and lift-and-slide doors.
The machine system consists of:
Weinig UC Matic 3-bay support table:
Automatic infeed to the moulder
Weinig Unikat 23EL moulder:
Year of manufacture: 2007
2 spindles below
2 spindles above
1 spindle right
1 spindle left
Glazing bead cutting
Glazing bead profiling
Hess Roto Finish grinding machine
Weinig Unirex cross-cut saw:
Cross-cut saw
Drilling unit
Lock case milling unit
Weinig United 15 tenoning machine
3 slotting spindles
Max. slot depth (mm): 120
Counter travels possible
Weinig Univar 12 rebating and profiling machine
Equipped with 7 spindles
Link to the Biesse System
Biesse WinLine One machining center
Built in 2015
Equipped with 2 gantries
Part length (mm) up to 6000
Max. part length in automatic mode (mm) 4500
Paternoster buffer
Gantry 1 equipped with saw, mobile tool changer
Gantry 2 equipped with lock case milling machine (FlexiWood), round-arch table
Biesse Flexstoor 1
Biesse Flexstoor 2
Sale of the complete system including tools
also including
Weinig U23E moulder
Built in 1998
Defective RAM without tools
Saturn steel grinding machine
