Saurer Epoca 2 16.3 yards

Can be used to embroider fabrics for lingerie, furnishing, ready-to-wear and guipure.
Can be configured according to the needle ratio program for large or small motifs,
and according to the color of the bobbins.
Automatically cuts the threads back and forth when the needle ratio changes and when the motif is completed.
Includes 552 English embroidery pins.
Embroiders 14.50 meters in length and 160 cm in width thanks to its 165 cm frame.
Total length of the machine: 18 meters
Can work with up to 552 new needles and shuttles.
Production speed is 360 stitches per minute.
Machine works with a floppy disk program.
Computer system is SLM.
White shuttle holders.
New monitoring screen.

General technical data:
Minimum needle ratio: 4/4 French inch = 27.07 mm
Lateral movement: Maximum ratio 120/4 = 810 mm
Lateral movement with transport: Maximum ratio 104/4 = 700 mm
Minimum stitch unit: 0.1 mm horizontally and vertically
Punching depth: 0 to 20 mm continuous (= max. ⌀4.2 mm for 12% punching)
Standard bobbin dimensions (WxD): 85 x 50 mm

Cones:
230 x 125 mm (4/4), embroidery height 1250/1650
200 x 150 mm (8/4), embroidery height 1250/1650
230 x 125 mm (8/4), embroidery height 850
Shuttles: Saurer TOP in steel or carbon ("Silenzio")
Size of the bobbins cocoons:
Steel 43 x 15.2 mm
Carbon 43(0/-0.2) x 14.7(0/-0.2) mm
Fabric roll ⌀:
unwound: ⌀80 mm;
wound: max. ⌀110 mm .
