Gaudino, Nsc schlumberger, Schlafhorst Spinning plant (preparation, spining, windeing)

Split sale possible as follows:
1. Preperation line
2. Spinning line
3. Winding Line


BLENDING AND DRAFTING MACHINES
1x Drafting Machine After Combing KAPICIOĞLU 2006
120 mt/min max speed
6 Doubling
0-60 mm Nip Distance
"Single Can 1 can 1 end" Coiler Type
"700*1200 mm" Cans Type
15*21*1 220mm 6/cm 72 pieces Front Side Faller Type

2x Drafting Machine After Blendig GN5 1983(1); 1984 (1)
120 mt/min max speed
6 Doubling
0-60 mm Nip Distance
"Single Can 1 can 1 end" Coiler Type
"600*1200 mm" Cans Type
"16*1 220mm 4/cm 72 pieces" Front Side Faller Type

2x Drafting Machine 1. Passage GC12
1988 (1) 300 mt/min max speed
1985(1) 350 mt/min max speed
8 Doubling
0-60 mm Nip Distance
"Single Can 1 can 1 end" Coiler Type
"700*1000 mm" Cans Type
"15*21*1 220mm 6/cm 144 pieces" Front Side Faller Type

Drafting Machine 1. Preperation Passage CSN ARM 1993
350 mt/min max speed
8 Doubling
0-60 mm Nip Distance
"Single Can 1 can 1 end" Coiler Type
"800*1000 mm" Cans Type
"16*22*1 220mm 6/cm 144 pieces" Front Side Faller Type

Drafting Machine 2. Preperation Passage GC12 1985
350 mt/min max speed
3*2 Doubling
0-60 mm Nip Distance
Double Cans 2 can*1 end Coiler Type
"700*1000 mm" Cans Type
"16*22*1 220mm 6/cm 144 pieces" Front Side Faller Type

Drafting Machine 3. Preperation Passage GC12 1985
300 mt/min max speed
3*4 Doubling
35-80 Nip Distance
Double Cans 4 can*4 end Coiler Type
"16*22*1 220mm 6/cm 144 pieces" Front Side Faller Type

Drafting Machine 4. Preperation Passage GV10 1991
4*2 Doubling
0-60 mm Nip Distance
"Single Can 1 can 1 end" Coiler Type
700*1000 mm Cans Type
baretli Front Side Faller Type

COMBING
1x PB30 138LF 1989
210 mt/min max speed
24 Doubling
28-40 Nip Distance
4,5-8,8 Feeding Distance
"Single Can 1 can 1 end" Coiler Type
600*900 mm cans type

4x PB30 138LF 1989
210 mt/min max speed
24 Doubling
28-40 Nip Distance
4,5-8,8 Feeding Distance
"Single Can 1 can 1 end" Coiler Type
700*1000 mm cans type

2x PB31 164LM 1993
210 mt/min max speed
24 Doubling
28-40 Nip Distance
4,5-8,8 Feeding Distance
"Single Can 1 can 1 end" Coiler Type
600*900 mm cans type

FINISHER
1x FMV30 1985
1x FMV32 1992
200 mt/min
24 Spindles

SPINNING
2 x SUESSEN FIOMAX 1996
640 SPINDLES
SUESSEN ELITE COMPACT SYSTEM
48 RING DIA
J.9,1 TRAVELLER TYPE
260 MM TUBE
82,5 GAUGE
MECHANICAL TOP ARM
AUTOMATIC DOFF

1x GAUDINO FPT 1998
576 SPINDLES
SUESSEN ELITE COMPACT SYSTEM
51 RING DIA
J.9,1 TRAVELLER TYPE
260 MM TUBE
82,5 GAUGE
MECHANICAL TOP ARM
NO AUTOMATIC DOFF

2x GAUDINO FPT 1998
640 SPINDLES
SUESSEN ELITE COMPACT SYSTEM
48 RING DIA
J.9,1 TRAVELLER TYPE
260 MM TUBE
75 GAUGE
PK 6000 TOP ARM
AUTOMATIC DOFF

2x GAUDINO FPT 1998
640 SPINDLES
SUESSEN ELITE COMPACT SYSTEM
48 RING DIA
J.9,1 TRAVELLER TYPE
260 MM TUBE
75 GAUGE
MECHANICAL TOP ARM
1x WITH AUTOMATIC DOFF
1x WITHOUT AUTOMATIC DOFF

1x GAUDINO FPT 1999
560 SPINDLES
SUESSEN ELITE COMPACT SYSTEM
51 RING DIA
J.9,1 TRAVELLER TYPE
260 MM TUBE
75 GAUGE
MECHANICAL TOP ARM
AUTOMATIC DOFF

2x GAUDINO FPT 2001
540 SPINDLES
SUESSEN ELITE COMPACT SYSTEM
48 RING DIA
J.9,1 TRAVELLER TYPE
260 MM TUBE
75 GAUGE
PK 6000 TOP ARM
AUTOMATIC DOFF

6 x SUESSEN FIOMAX 1995/1999
576 SPINDLES (5 sets) 624 SINDLES (1 set)
SUESSEN ELITE COMPACT SYSTEM
48 RING DIA
J.11,1 TRAVELLER TYPE
240 MM TUBE
75 GAUGE
MECHANICAL TOP ARM
AUTOMATIC DOFF

WINDING
2x Savio Espero (1x1996; 1x )
Magazine type
60 spindles
Noter splicer type
Uster Quantum 2 Optic yarn cleaner
TRAVELLING CLEANERS
1 doffer
Steel Drum type
6” 2-pitch drum

1x SCHLAFHORST 238 1995
Automotic Type
30 spindles
Thermo splicer type
Uster Quantum 2 Optic yarn cleaner
TRAVELLING CLEANERS
1 doffer
Steel Drum type
6” 2-pitch drum

2x SCHLAFHORST 338 GOLD RM 2005
60 spindles
Thermo splicer type
Uster Quantum Capacitif yarn cleaner
TRAVELLING CLEANERS
1 doffer
Steel Drum type
6” 2-pitch drum
