Niagara BN-80-OBS Press 88 TON

Niagara BN-80-OBS Press
CAPACITY 88 TONS
STROKE 6″
max. shut height to bed 19″
RAM ADJUSTMENT 4.5″ MOTORIZED
BED AREA 36″ X 24″ (RL X FB)
RAM AREA 24″ X 18″ (RL X FB)
BOLSTER SIZE 36.25” X 24” (RL X FB) X 5” THICK T-SLOTTED BOLSTER PLATE
SPEED 40-75 SPM
THROAT DEPTH 13″
DISTANCE BETWEEN UPRIGHTS 25″
FLOOR TO BED 35”
CLUTCH NIAGARA AIR CLUTCH & BRAKE
PRESS CONTROLS WINTRISS SMARTPAC CONTROLLER, OMNILINK LCD OPERATOR TERMINAL
ELECTRICAL 15 HP 230/460V-3-60 TECO WESTINGHOUSE MOTOR | 34.6/17.3 AMPS
APPROX. DIMENSIONS 90” X 73” (RL X FB) X 125” HIGH
APPROX. WEIGHT 12,000 LBS.
Equipped With WINTRISS SMARTPAC MODULE AUTOSETPAC WINTRISS LOAD ANALYZER
