Krefeld, Kusters 222.54 / 5200 520 Cm Finishing Mangle
EUROPE (Western and Northern)
Type of machine Finishing Mangle
Make KUESTERS, KREFELD
Type 222.54 / 5200
Year of manufacture refurbished
Type of control conventional
Working widths 5200 mm
Roller width 5400 mm
Number of rollers 2 Stück
Supporting roller - dia 490 mm
Roller covering - soft rubber 75 Grad shore
Swimming roll - dia 340 mm
Roller covering - soft rubber 75 Grad shore
Pressure line 35 N / mm
Pressure total 19 to
Cloth guiding system-wide support, a guide roller
Liquor trough with guide roll + raised lowered
Drive side to Order
Opera Starting side by Order
Pneumatic compensator. discharge
Drive shaft diameter 70 mm
required power 30 m / min = 10 kW
Hydraulic unit for combined pressure stainless steel
Additional information
• Machine will be completely overhauled before delivery, we supply with warranty
(Photo shows an overhauled machine in delivery-status)
• additional new frequency drive for adaptation into a plant is possible
