Horizon BQ 470DN PUR

The Horizon BQ-470DN Fully Automated, 4-Clamp Perfect Binder incorporates the PUR binding mechanism
and features an interchangeable glue tank, for both EVA and PUR adhesives.
Counter: only 0,94 mil. books
Technical specifications :
max. book size 320 × 320 mm
min. book size 145 × 105 mm
max. cover size 320 × 660 mm
min. cover size 135 x 225 mm
cover material density 82...300 g/m2 (coated paper 105...350 g/m2)
book thickness from 1 to 65 mm
max. productivity of 1’000 books/hour (when working with PUR glue)

Package contents :
4 block clips (carriages)
manual block feeding
spine preparation section: milling, backbone roughing (high-speed milling cutter), scraps and dust removal
automatic vacuum self-sealing of covers with creasing function
double cover feed control
Nordson replacement station for preparing and feeding PUR glue with a separate tank
EVA glue side sizing device with glue temperature control function
book spine crimping station with adjustable crimping force
receiving conveyor
control panel with color touch screen and touch&work interface, a complete set of technical documentation.
The device is fully functional and ready to work.
