DL110-IQ 100 T
Ref :
2166648-6-GO
Condition :
Used
Manufacturer :
-
Model :
DL110-IQ
Capacity :
100 T
Year(s) :
1999
Quantity :
1
Location :
Seller or machines location:
ASIA (South)
ASIA (South)
Last check :
02 Jan. 2025
SHINEWA
clamping force 110TON
screw diameter 36 mm
shot weight PS 140 g
shot volume 1820 cm
injection pressure 1840 kgf/1/2
tie bar distance H x V 460 x 460 mm
mould height min 205 mm
mould opening stroke 545 mm
Total Opening ( Daylight) 750mm
Ejector stroke 125 mm
Ejector Force 8.3 Ton
main motor 45 Kw
heating total Load 15.6 Kw
machine weight 14.4 Ton
dimensions of the machine L x W x H 4.95 x 1.74 x 1.2 m
Oil Tank 300
