Alco ASK PRO COMPACT 400 DD-SS

This spiral freezer,
type: Alco ASK PRO COMPACT 400 DD-SS was built in 2022 in Germany.
It is perfectly designed for rapid individual quick freezing
(IQF method) and chilling of products.
Compact, transportable machine on a stable base frame
maximum belt length on a minimum footprint
direct drive belt system
horizontal airflow technology
Powerful evaporator and fan units
PLC control with display
short assembly and commissioning times
inkl. water defrosting system
inkl. Cleaning Sytem

Technical Details
Layout: 0°- infeed south, 180°-outfeed south
Direction of rotation: clockwise
Conveyor direction: up
Infeed height: 975 mm
Discharge height: 3.100 mm
Belt infeed length: approx. 400 mm + separate infeed belt
Retention time: 20 - 60 min
Cooling capacity: 100 kW
Refrigerant: R449A DE (Dewpoint)
Net belt width: 417 mm
Drum diameter: 1.505 mm
Number of tiers: 24,5
Clearance between tiers: 60 mm
Max product height: 40 mm
Belt surface: 70 m²
Belt tracking control: belt tension control
Voltage: 400 V / 50 Hz, 3 phases + PE
Length: 7.300 mm
Width: 3.500 mm
Height: 4.465 mm

Scope of delivery
